Lighting Information

Lighting Information

  1. Control Board (located in control booth at rear of balcony) ETC Ion & ETC Express 125 available
  2. Dimmers -96 available- Sensor. Circuit per dimmer; each dimmer has capacity of 2.4k
  3. Lighting info
    • Connectors - 20 amp, 250 v. Grounded Stage Pin
    • 1st Electric* - batten #3, 3'-1" from plasterline, 16 circuits, 32 connectors (some circuits repeat)
    • 2nd Electric - located on batten #8, 8'-3" from plasterline
    • 3rd Electric* -Located on batten #14, 13'-10" from plasterline
    • 4th Electric -Located on batten #21, 19'-1" from plasterline
    • Tormentor Positions -there are 6 circuits available both SR and SL.
    • Gallery Positions - 4 circuits per gallery; may be cabled to booms or battens.
    • Front of House Ceiling Cove Positions - Total of 20 circuits available (3 right cove, 14 center, 3 left cove). We do not have boxbooms or a balcony rail.

    • Lighting Instruments and Equipment **

      1. 24 Source Four ellipsoidals (26 degree), lamped at 575 W.

      2. 12 Source Four ellipsoidals (19 degree), lamped at 575 W.

      3. 24 Source Four PARs, 575 W, with wide flood lenses.

      4. 24 Source Four Parnels lamped at 575 W.

      5. 4 Source Four ellipsoidals (36 degree), lamped at 575 W.

      6. One (1) Altman Comet Follow Spot, 360 W (two available).

*These electrics are rigged with a tandem batten for hanging instruments. Arbor capacity limits the amount of weight that may be added to this batten (maximum 400 lbs.).

FOH

Position

Distance From Proscenium*

Height Above Stage Floor

Length

Center Cove
39'- 9"
20'-10"
23'- 0"
Right Cove
45'- 3"
20'-10"
7'-0"
Left Cove
45'- 3"
20'-10"
7'-0"

*Measured at an angle from cove to stage floor at plasterline. Coves are 26'6" from proscenium when measured horizontally.

**Additional instruments can be rented locally.
